Introduction

Introducing our Static Pass Box – the ideal solution for controlled access and contamination prevention. Our Static Pass Box offers seamless material transfer while adhering to the highest cleanliness standards. With advanced features and robust construction, it ensures a hygienic environment for critical operations. Equipped with an interlocking mechanism and HEPA filters, our Pass Box prevents cross-contamination and delivers superior air purification. Safety features like door open alarms and a reliable fire suppression system provide added protection. Discover the efficiency and reliability of our customizable Static Pass Box for your specific industry needs.

Brinda Pharma Technologies is a leading manufacturer & exporter of quality clean room air showers for various applications in the following areas:

Pharmaceutical
Bio-Technology
Laboratory
Micro-Electronics
Aerospace

API Manufacturing
Excipient Manufacturing
Food Manufacturing
Advance Indoor Agriculture

Ensure superior cleanliness and efficiency in your manufacturing process with our advanced De-Dusting Tunnel. Designed to remove loose particles of dust and particulate matter that accumulate on raw material containers like drums, cartons boxes, sacks, or bags prior to sampling or dispensing, our De-Dusting Tunnel offers unmatched performance and reliability. Brinda Pharma Technologies is a trusted manufacturer and exporter of high-quality De-Dusting Tunnels, providing solutions for pharmaceutical industries worldwide.

.slick-loading .slick-list{--wpr-bg-fd3f4e6e-6c26-4654-b6b7-6937507b615d: url('https://brindapharma.com/wp-content/plugins/ht-mega-for-elementor/assets/images/ajax-loader.gif');}.rs-layer.slidelink a div{--wpr-bg-99013140-89cf-4b47-be3e-91aa87b7d8d6: url('https://brindapharma.com/wp-content/plugins/revslider/public/assets/assets/coloredbg.png');}.rs-layer.slidelink a span{--wpr-bg-6b15afca-e9af-4d48-975e-a5a66c3e6bb6: url('https://brindapharma.com/wp-content/plugins/revslider/public/assets/assets/coloredbg.png');}.elementor-17724 .elementor-element.elementor-element-8c5f10f:not(.elementor-motion-effects-element-type-background),.elementor-17724 .elementor-element.elementor-element-8c5f10f>.elementor-motion-effects-container>.elementor-motion-effects-layer{--wpr-bg-6f2e576e-4ba8-4e36-aebd-bd3b795c11f8: url('https://brindapharma.com/wp-content/uploads/2024/08/brinda-pharma-04-scaled.jpg');}.iti-flag{--wpr-bg-071e0915-d52c-4efa-b956-1efd862dc3e3: url('https://brindapharma.com/wp-content/plugins/international-telephone-input-for-contact-form-7/vendor/intl-tel-input/img/flags.png');}#page{--wpr-bg-93974833-d9e8-457c-9647-078bef213f88: url('https://brindapharma.com/portfolio/de-dusting-tunnel/?nowprocket=1&no_optimize=1&wpr_imagedimensions=1');}.rll-youtube-player .play{--wpr-bg-9acd7837-8195-4c56-a30a-5311c211e6fc: url('https://brindapharma.com/wp-content/plugins/wp-rocket/assets/img/youtube.png');}

Features

Efficient Dust Removal: Our De-Dusting Tunnel effectively removes loose particles of dust and particulate matter from raw material containers, ensuring cleanliness and compliance with regulatory standards.
High-Speed Operation: With high-speed conveyors and powerful air jets, our De-Dusting Tunnel transfers the material quickly and efficiently, minimizing downtime and maximizing productivity.
Adjustable Settings: The De-Dusting Tunnel features adjustable settings for airflow, conveyor speed, and dust removal intensity, allowing for customization to suit specific production requirements.
Easy Maintenance: The system is designed for easy maintenance with accessible filter replacement, user-friendly control interfaces, and built-in monitoring systems to ensure consistent and reliable operation with minimal downtime.
Compliance with Industry Standards: Our Air Shower System exceeds industry standards for Air Quality control. We do also provide all the documents and protocols to ensure our client is consistently meeting the GMP & Regulatory Compliance requirements.

Features

Efficient Dust Removal: Our De-Dusting Tunnel effectively removes loose particles of dust and particulate matter from raw material containers, ensuring cleanliness and compliance with regulatory standards.
High-Speed Operation: With high-speed conveyors and powerful air jets, our De-Dusting Tunnel transfers the material quickly and efficiently, minimizing downtime and maximizing productivity.
Adjustable Settings: The De-Dusting Tunnel features adjustable settings for airflow, conveyor speed, and dust removal intensity, allowing for customization to suit specific production requirements.
Easy Maintenance: The system is designed for easy maintenance with accessible filter replacement, user-friendly control interfaces, and built-in monitoring systems to ensure consistent and reliable operation with minimal downtime.
Compliance with Industry Standards: Our Air Shower System exceeds industry standards for Air Quality control. We do also provide all the documents and protocols to ensure our client is consistently meeting the GMP & Regulatory Compliance requirements.

Working Principle

The De-Dusting Tunnel operates on a simple yet effective principle. De-Dusting Tunnel is usually placed in the Primary Warehouse so that all incoming material like drums, cartons boxes, sacks, or bags is cleaned before stacking them in the warehouse. This process allows for maintaining cleanliness in the warehouse.

The material is placed on the entry side of the De-Dusting Tunnel conveyor, the conveyor takes the material inside the chamber of de-dusting tunnel in which high velocity air is blown on the surface of these material using air nozzle. A separate nylon cleaning brush helps remove the hard residue from the surface as well. All dust is later collected in dust collector. Upon completion of this cycle the conveyor takes out the material from the chamber and allows uses to stack or place it in the warehouse. The adjustable settings allow for precise control of airflow and intensity, ensuring thorough dust removal without compromising container integrity.

Models

Accessories

Accessory	Description
Clean Down Timer	Timer feature for scheduling and automating the cleaning process, ensuring consistent cleanliness.
Pilot Light	Indicator light to signal the operational status of the system, providing visual feedback to users.
Buzzers	Audible alarms or buzzers to alert users of any anomalies or safety concerns, enhancing system safety.
HMI+PLC Based Control System	To monitor and change various parameters from a single touchscreen interface which makes entire system easy to operate.

FAQs

What types of industries use De-Dusting Tunnels?
De-dusting tunnels are commonly used in industries such as food processing, pharmaceuticals, packaging, manufacturing, and any other industry where cleanliness and hygiene are important.

What are the benefits of using a De-Dusting Tunnel?
Some of the benefits of using a de-dusting tunnel include:

Improved product quality by removing contaminants.
Increased hygiene and cleanliness of the products and area
Reduction in equipment maintenance due to minimized dust accumulation.
Compliance with industry regulations and standards.
Enhanced worker safety by reducing dust exposure.

Are De-Dusting Tunnels customizable for different requirements?
Yes, de-dusting tunnels can be customized to meet specific requirements. Brinda Pharma Technologies helps clients in building a customized solution. The specification of the de-dusting tunnel depends of the size the drums, cartons boxes, sacks, or bags and the frequency of the incoming material. A proper customized solution can help you improve productivity as well as maintain the cleanliness.

Are De-Dusting Tunnels easy to maintain?
De-dusting tunnels generally require regular maintenance to ensure optimal performance. This includes cleaning and inspecting the brushes, air jets, suction systems, or other components to remove any debris or build-up that may affect their efficiency.

Can De-Dusting Tunnels be integrated into existing facilities?
Yes, de-dusting tunnels can be integrated into existing facilities. There might be a need of a detailed analysis to ensure its feasible to install the De-Dusting Tunnel.

Are there any safety considerations when using de-dusting tunnels?
Safety is an important consideration when using de-dusting tunnels as it is considered as heavy equipment. Adequate safety measures should be in place to protect workers from hazards such as moving parts, high-pressure air jets, or electrical components. Workers should receive proper training on the safe operation and maintenance of the equipment.

Can a de-dusting tunnel eliminate all contaminants?
While de-dusting tunnels are effective at removing loose dust and particles from the surface of products, they may not eliminate all types of contaminants. For certain applications requiring higher levels of cleanliness, additional processes or equipment may be necessary.

Does Brinda Pharma Technologies provide delivery & installation to my destination
As a leading manufacturer and exporter we provide delivery orders across the world. We also provide products with installation & validation, as well as an annual maintenance contract to ease your operation. Reach out to our Sales Team to discuss any questions related to Delivery & Installation.

Accessory	Description
Pressure Gauge	Accurate pressure gauge for monitoring and maintaining optimal airflow and pressure levels.
Clean Down Timer	Timer feature for scheduling and automating the cleaning process, ensuring consistent cleanliness.
Pilot Light	Indicator light to signal the operational status of the system, providing visual feedback to users.
Buzzers	Audible alarms or buzzers to alert users of any anomalies or safety concerns, enhancing system safety.
UV Light	UV light for sterilization and improved contamination control
HMI+PLC Based Control System	To monitor and change various parameters from a single touchscreen interface which makes entire system easy to operate.
Flame Proof System (FLP)	A Complete or partial Flame Proof System along with FLP Lights to accommodate safe working environment and prevent fire hazards.
